| Brand | Uni-T |
| Measuring range DC and AC voltage | DC 1000V ±(0.025%+5)
AC 1000V ±(0.3%+30); Frequency of response: 40~500Hz |
| DC and AC current measuring range | DC 10A ±(0.08%+10)
AC 10A ±(0.6%+20); Frequency of response: 40~500Hz |
| Resistance measuring range | 60MΩ ±(0.05%+2) |
| Capacitance measuring range | 60mF ±(2%+5) |
| Frequency measurement range | 10Hz~60MHz ±(0.01%+5) |
| Temperature measurement range | -40°C~1000°C ±(1%+30) |
| Display accounts | Up to 60000 |
| Auto Range / Manual Range / True RMS | Yes, it has |
| Bandwidth | 100 kHz |
| Relative mode | Yes, it is available |
| Data logging | 20000 |
| Continuity test | Yes, it is available |
| Low pass filter | 1 kHz |
| Diode test | Up to 3V |
| Dual temperature measurement | T1, T2, T1-T2, T2-T1 |
| Input protection | Yes, it is available |
| DC input impedance | ≥10MΩ |
| Power | Lithium Battery 2200 mAh 7.4V |
| Dimensions | 195 (H) x 95 (W) x 58 (D) mm |
| Weight | 638.6 g |
| Security | CAT III 100V/ CATIV 600V CATIV [%VAR%] |
