Varenr. AK-R28A

Akuvox 4,3" dørstation, IP65, MF / EM

Name: Akuvox 4,3" dørstation, IP65, MF / EM
Brand: Akuvox
SKU: AK-R28A
Price: 8322.00 DKK
Availability: InStock

Hent datablad

Beskrivelse

Akuvox R28 er en SIP video dørtelefon med et numerisk tastatur. Det bruges typisk i etageejendomme.

Vandalsikker
Vidvinkelkamera: 116º (H), 60º (V);
PoE (IEEE802.3af, Power-over-Ethernet);
To-vejs lydkommunikation over IP-netværk med Echo Cancel-funktion;
Overholder SIP-standarden for nem integration i alle SIP-kompatible PBX'er;
Overholder ONVIF-standarden for nem integration med ethvert netværksovervågningssystem;

Brand	Akuvox
Model	R28A
Access control	Door opening with RFID card EM 125 kHz and MF 13.56 MHz and PIN, with records
Capacity	Contacts: 1.000 RFID users: 5.000 cards/passwords
Keypad	Mechanical numeric call button panel with configurable LED illumination
Screen	4.3" TFT LCD full color
Outputs	3 of relay for main locks (12V/400mA), Wiegand OUT and RS485
Inputs	3 pushbutton and Wiegand IN inputs
Remote access	SmartPlus cell phone application or configuration via WEB browser Remote access by Cloud: Included
Image sensor	1/2.7" 2 Megapixel CMOS with infrared sensor and light sensor
Viewing Angle	116° (H) / 60° (V)
Camera resolution	1920x1080 - 25fps / CIF, QCIF, VGA, 4CIF, 720p, 1080p
Video encoding	H.264 y H.265
Audio	Two-way audio with noise-reduced microphone and speaker with Crystal Clear Audio technology
Audio Format	SIP v1 (RFC2543), SIP v2 (RFC3261), G.711a, G.711μ, G.729, G.722 DTMF (RFC2833), SIP Info
Network interface	Ethernet 10/100 BaseT / RS485 / RTSP
Mode of operation	Local network and/or via cloud in different networks
Firmware updates	Remote with cloud via installer account or via web browser locally
Material	Aluminium alloy
Degree of protection	IP65
Temp. operation	-40º C ~ +55º C
Dimensions	With surface support: 280 (H) x 130 (W) x 38 (D) mm With flush mounting bracket: 280 (H) x 130 (W) x 68 (D) mm
Power	DC 12 V / 1000 mA máx. / IEEE802.3af PoE
Weight	1000 g

Download dokumenter
