| Brand |
SAFIRE |
| Image sensor |
1/3" Progressive Scan CMOS |
| Maximum resolution |
4 Megapixel (2688x1520) |
| Main Stream rate |
25 fps (2688x1520, 1920x1080, 1280x720) |
| Sub Stream Rate |
25 fps (640×480, 640x360, 320×240) |
| Third Stream Rate |
25 fps (1280x720, 640x360, 352x288) |
| Compression |
H.265+, H.265, H.264+, H.264 |
| Bitrate |
32 Kbps ~ 16 Mbps |
| Lens |
2.8 mm (H: 103º, V: 55º) |
| Minimum illumination |
0.005 Lux (colour) / 0 Lux (B/N) |
| Infrared lighting |
0 Lux / IR LEDs (30 m) |
| Image improvements |
WDR (120 dB), BLC, 3D-DNR, AWB, ROI, Motion detection, Mirror |
| Day / Night |
Removable mechanical ICR filter |
| Motion Detection 2.0 |
Advanced motion detection of humans and vehicles on the scene |
| Intelligent functions |
Line Crossing, Area Intrusion, Face Detection |
| Audio |
Integrated microphone |
| Network interface |
Ethernet 10/100 BaseT |
| Storage |
MicroSD card slot up to 256GB, NAS |
| Remote access |
Web browser, Safire Control Center Smartphone App and PC Software |
| Interoperability |
ONVIF, PSIA, CGI, ISAPI |
| Power |
12 VDC / 500 mA (MAX 6W), PoE 802.3af |
| Degree of protection |
Weatherproof IP67 |
| Temp. Functioning |
-30º C ~ +60º C |
| Dimensions |
Ø127.3 × 95.9 mm |
| Weight |
600 g |
